065″ AND 069″ FENCE TUBES and Panel

SIZE（OD” * WT” * L(FT) OD Wall Thickness Length PCS/ BUNDLE TONS/ BUNDLE
inch mm inch mm FT mm
.065″ FENCE TUBES 1.315″X.065″X18′ 1.315 33.4 0.065 1.65 18 5486 91 0.645
1.660″X.065″X18′ 1.660 42.2 0.065 1.65 18 5486 61 0.552
1.900″X.065″X18′ 1.900 48.3 0.065 1.65 18 5486 61 0.635
2.375″X.065″X18′ 2.375 60.3 0.065 1.65 18 5486 37 0.484
1.315″X.065″X21′ 1.315 33.4 0.065 1.65 21 6400 91 0.752
1.660″X.065″X21′ 1.660 42.2 0.065 1.65 21 6400 61 0.644
1.900″X.065″X21′ 1.900 48.3 0.065 1.65 21 6400 61 0.741
2.375″X.065″X21′ 2.375 60.3 0.065 1.65 21 6400 37 0.565
1.315″X.065″X24′ 1.315 33.4 0.065 1.65 24 7315 91 0.860
1.660″X.065″X24′ 1.660 42.2 0.065 1.65 24 7315 61 0.736
1.900″X.065″X24′ 1.900 48.3 0.065 1.65 24 7315 61 0.847
2.375″X.065″X24′ 2.375 60.3 0.065 1.65 24 7315 37 0.646

1. Hot dipped galvanized.

2. Plain Ends.

3. Plastic sheet covered and the packaged by 3+2+2+3 Gal steel strips.

4. Shipped by 20GP or 40GP or by bulk.

Fence Panel

Panels:12″*6″，10″*6″，10″*8″

Stands:30″*16″,36″*16″

SIZE（OD” * WT” * L(FT) OD Wall Thickness Length PCS/ BUNDLE TONS/ BUNDLE
inch mm inch mm FT mm
.069″ FENCE TUBES 1.315″X.069″X18′ 1.315 33.4 0.069 1.75 18 5486 91 0.682
1.660″X.069″X18′ 1.660 42.2 0.069 1.75 18 5486 61 0.584
1.900″X.069″X18′ 1.900 48.3 0.069 1.75 18 5486 61 0.672
2.375″X.069″X18′ 2.375 60.3 0.069 1.75 18 5486 37 0.513
1.315″X.069″X21′ 1.315 33.4 0.069 1.75 21 6400 91 0.795
1.660″X.069″X21′ 1.660 42.2 0.069 1.75 21 6400 61 0.681
1.900″X.069″X21′ 1.900 48.3 0.069 1.75 21 6400 61 0.784
2.375″X.069″X21′ 2.375 60.3 0.069 1.75 21 6400 37 0.598
1.315″X.069″X24′ 1.315 33.4 0.069 1.75 24 7315 91 0.909
1.660″X.069″X24′ 1.660 42.2 0.069 1.75 24 7315 61 0.779
1.900″X.069″X24′ 1.900 48.3 0.069 1.75 24 7315 61 0.896
2.375″X.069″X24′ 2.375 60.3 0.069 1.75 24 7315 37 0.684
